Streamlining SSH Key Management

Introduction

When working with multiple servers, SSH keys are indispensable for secure authentication. Early in my workflow, I relied on a single key pair reused across all systems. While convenient, this practice introduces a major security risk: if that key is compromised, every connected server is at risk.

Table of Contents

1. Introduction
2. The Role of .ssh/config
3. How the Script Works
   • 1. Server Directory
   • 2. File Permissions
   • 3. Generating the Keys
   • 4. Creating the Config File
   • 5. Linking to .ssh/config
   • 6. Testing the Connection
4. Example Run
5. Why This Matters
6. Next Steps

---

A safer approach is to generate unique key pairs per server. The challenge, however, is that managing dozens of keys can quickly clutter your .ssh directory. To solve this, I created a Bash script that automates key generation, keeps configurations organized, and makes connecting to servers seamless.

---

Leveraging the .ssh/config File

The .ssh/config file defines how you connect to different servers. Some of the most common parameters include:

• Host – The alias you’ll use for quick access.
• HostName – The server’s IP address or DNS record.
• User – The login username.
• IdentityFile – The private key file for authentication.

By splitting configurations into include files, SSH setups become easier to manage. My script automates this by generating per-server config files and linking them back to your main .ssh/config.

---

How the Script Works

The script takes three inputs—hostname, IP address, and username—and handles everything else automatically:

1. Creates a secure directory for keys and configuration.
2. Generates a new SSH key pair.
3. Copies the public key to the target server.
4. Builds a dedicated config file.
5. Updates the main .ssh/config to include the new entry.
6. Tests the connection.

---

1. Server Directory

Each server gets its own folder under ~/.ssh/include.d/ for keys and configs:

config_directory=/home/${local_user}/.ssh/include.d/${host_name}
mkdir -p ${config_directory}

---

2. File Permissions

Security starts with proper permissions. The script enforces strict ACL rules to keep your keys safe:

setfacl -d -m u::rw,g::-,o::- ${config_directory}

---

3. Generating the Keys

It then creates a new ed25519 key pair (with no passphrase by default) and pushes the public key to the remote server:

ssh-keygen -t ed25519 -f ${config_directory}/${host_name} -N ""
ssh-copy-id -i ${config_directory}/${host_name}.pub ${user}@${ip_address}

---

4. Creating the Config File

Next, a lightweight config file is generated for the server:

cat <<EOL > ${config_directory}/config
Host ${host_name}
     HostName ${ip_address}
     User ${user}
     IdentityFile ${config_directory}/${host_name}
EOL

---

5. Linking to .ssh/config

The script ensures your main config file includes the new entry automatically:

echo "Include ${config_directory}/config" | cat - ~/.ssh/config > temp_file && mv temp_file ~/.ssh/config

---

6. Testing the Connection

Finally, it validates the setup by attempting a login:

ssh ${host_name}

If successful, you can now connect to the server with a simple:

ssh <hostname>

---

Example

Running:

create_ssh_login.bash proxmox 192.168.177.7 richard

Produces the following structure:

~/.ssh
├── config
├── include.d/
│   └── proxmox/
│      ├── proxmox
│      ├── proxmox.pub
│      ├── config

---

Why This Matters

This script makes it easy to:

• Improve SSH key security by using unique keys per server.
• Keep the .ssh directory neat and manageable.
• Simplify connections with one-line ssh <alias> commands.

For the full script, visit GitHub: Streamlining-SSH-Key.
